Bridge Grades Calculation: Final Bridge Grade Calculation Engine

Bridge Grades Calculation: Final Bridge Grade Calculation Engine#

Overview

This notebook serves as the central scoring engine for the Bridge Grades methodology, combining all processed data sources to calculate final Bridge Grades for members of the 119th U.S. Congress. It implements the complete scoring algorithm that transforms raw collaboration metrics into letter grades (A, B, C, F) that identify “bridgers” from “dividers.”

The notebook processes data from different sources (A, B, C, D, E, F, M, N, P) and applies configurable weights to generate normalized scores that are then converted to final Bridge Grades.

Data Sources#

Input Files#

All processed data sources from previous notebooks:

119th_Congress_20250809.csv - Master congressional roster with bioguide IDs, states, districts, parties, and chambers
bridge_grade_source_a_cross_party_supported_bills.csv - Source A: Authors of bills with cross-party sponsors
bridge_grade_source_b_cross_party_cosponsors.csv - Source B: Cosponsors of cross-party bills
bridge_grades_source_cdef_app_communication.csv - Source C/D/E/F: APP communications data (bipartisanship and personal attacks)
bridge_grade_source_m_house_pvi.csv - Source M: Cook Political PVI for House districts (House)
bridge_grade_source_m_senate_pvi.csv - Source M: Cook Political PVI for House districts (Senate)
bridge_grade_source_n_house_ideology.csv - Source N: VoteView ideological scores (House)
bridge_grade_source_n_senate_ideology.csv - Source N: VoteView ideological scores (Senate)
problem_solvers.csv - Source P: Problem Solvers Caucus
profiles.csv - Attendance data for filtering

Output Files#

house_scores_119.xlsx - Complete House member scores and grades
senate_scores_119.xlsx - Complete Senate member scores and grades

Main Functions#

1. Configuration and Setup#

Purpose: Sets up scoring parameters and loads all data sources

Key Parameters:

att_pct = 0.2 - Minimum attendance threshold (20%) for grading eligibility
weights - Configurable weights for each data source (A=3, B=3, C=1, D=1, etc.)
bonus_scaling_factor: scaling factors that control the effect of bonuses on the score. (All these factors were sought by methodologies assigned individually to each one)

Code Example:

att_pct   = 0.2    # minimum attendance proportion

weights   = {
    'A': 3,     # Source A: num_bills_with_cross_party_cosponsors
    'B': 2,     # Source B: num_cross_party_cosponsored_bills
    'C': 1,   # Source C: communications that support members of the opposite party
    'D': 1,   # Source D: proportion of communications that support members of the opposite party
    'E': 1,   # Source E: communications classified as personal attacks
    'F': 1,   # Source F: proportion of communications classified as personal attacks
}

bonuses = {
    'pvi_value_cap': 15, # number of PVI points to cap at
    'max_P_bonus_scaling_factor': 0.01, # scaling factor for P bonus
    'max_N_bonus_scaling_factor': 0.05, # scaling factor for N bonus
    'max_M_bonus_scaling_factor': 0.38 # scaling factor for M bonus
}

2. Attendance Filtering#

Purpose: Removes members with attendance below threshold from grading

Process:

Calculates attendance percentage for each member
Filters out members below 20% attendance threshold
Applies filtering to both House and Senate datasets

3. Data Source Integration#

Purpose: Merges all processed data sources into master datasets

For Each Source (A through F):

Loads processed CSV file
Merges with master dataset using bioguide_id
Fills missing values appropriately (0 for counts, mean for percentages)
Calculates normalized scores using normal distribution CDF
Renames columns with source prefix for clarity

4. Final Score Calculation#

Purpose: Combines all normalized scores using weighted algorithm

Algorithm:

def cal_score(data, weights, bonuses):
    # Copy the data to avoid modifying the original dataframe
    temp_data = data.copy()

    # Initialize columns
    temp_data['score_T'] = 0

    # Calculate 'score_T' by adding weighted norm values for each category
    for i in weights.keys():
        temp_data['score_T'] += temp_data[f"norm_{i}"] * weights[i]


    # Calculate scores for ideology multipliers BEFORE the caucus score
    # Add bonuses
    temp_data['bonus_m'] = (temp_data['score_T']*(1+(temp_data['Cook PVI Raw']/100)*bonuses['max_M_bonus_scaling_factor']))-temp_data['score_T']


    temp_data['bonus_n'] = temp_data['score_T'] * bonuses['max_N_bonus_scaling_factor'] * temp_data['ideology_dist']

    #the bonuses M and N to 0 if they are negative

    temp_data['bonus_m'] = temp_data['bonus_m'].clip(lower=0)
    temp_data['bonus_n'] = temp_data['bonus_n'].clip(lower=0)


    temp_data['bonus_p'] = np.ceil(
      bonuses['max_P_bonus_scaling_factor']
      * temp_data['score_T'].max()
      * temp_data['P_flag']
    ).astype(int)

    print( temp_data['bonus_p'] )
    print(temp_data['score_T'].max())

    temp_data['score_U'] = temp_data['score_T'] + temp_data['bonus_m'] + temp_data['bonus_n'] + temp_data['bonus_p']

    # Calculate mean, std, and median of 'score_S'
    mean_U = round(temp_data['score_U'].mean(), 2)
    std_U = round(temp_data['score_U'].std(), 2)
    median_U = round(temp_data['score_U'].median(), 2)

    # Normalize 'score_U' using the cumulative distribution function (CDF)
    temp_data['norm_U'] = norm.cdf(temp_data['score_U'], mean_U, std_U) * 100

    # Define the grade assignment function based on the calculated scores
    def assign_grade(grade):
        if grade > mean_U + std_U:
            return 'A'
        elif grade > median_U:
            return 'B'
        elif grade > mean_U - std_U:
            return 'C'
        else:
            return 'F'

    # Apply the grade assignment to the 'score_S' column
    temp_data['Grade'] = temp_data['score_U'].apply(assign_grade)

    return temp_data

Outputs#

Final Datasets#

House Scores Dataset (house_scores_119.xlsx)
- All House members with complete scoring breakdown
- Individual source scores and normalized values
- Final composite score and letter grade
Senate Scores Dataset (senate_scores_119.xlsx)
- All Senate members with complete scoring breakdown
- Individual source scores and normalized values
- Final composite score and letter grade

Key Columns in Output#

Identification: Name, Chamber, bioguide_id, State, District, Party
Raw Source Data: A through F source values
Normalized Scores: norm_A through norm_F (0-100 scale)
Composite Scores: score_T (base), score_P (caucus), score_M (PVI), score_N (ideology), score_U (final)
Final Results: norm_U (normalized final), Grade (A/B/C/F)

Technical Requirements#

Dependencies#

pandas - Data manipulation and analysis
numpy - Numerical operations
scipy.stats - Statistical functions (normal distribution CDF)
seaborn - Data visualization
matplotlib.pyplot - Plotting

Data Processing Notes#

Missing Value Handling: Fills missing values with 0 for counts, column mean for percentages
Duplicate Removal: Removes duplicate bioguide_id entries
Data Type Conversion: Converts numeric columns to appropriate types for export
Chamber Separation: Processes House and Senate separately due to different data structures

Data Quality#

Validation Checks#

Attendance Filtering: Removes members below 20% attendance threshold
Duplicate Handling: Removes duplicate bioguide_id entries
Missing Data: Appropriate filling strategies for each data type
Score Validation: Ensures all scores are within expected ranges

Notebook Walkthrough: Bridge Grades Calculation#

Configuration & File Existence Checks#

In this section we verify that all input files exist before proceeding, and validate that our weights dictionary matches the set of loaded source labels.

import os
import pandas as pd
import numpy as np
from datetime import datetime
from scipy.stats import norm

# Global parameters
att_pct   = 0.2    # minimum attendance proportion
weights   = {
    'A': 3,     # Source A: num_bills_with_cross_party_cosponsors
    'B': 2,     # Source B: num_cross_party_cosponsored_bills
    'C': 1,   # Source C: communications that support members of the opposite party
    'D': 1,   # Source D: proportion of communications that support members of the opposite party
    'E': 1,   # Source E: communications classified as personal attacks
    'F': 1,   # Source F: proportion of communications classified as personal attacks
}

bonuses = {
    'pvi_value_cap': 15, # number of PVI points to cap at
    'max_P_bonus_scaling_factor': 0.01, # scaling factor for P bonus
    'max_N_bonus_scaling_factor': 0.05, # scaling factor for N bonus
    'max_M_bonus_scaling_factor': 0.38 # scaling factor for M bonus
}

# Define all required file paths
BASE_DIR = '/content/drive/MyDrive/Bridge Grades Snapshot August/Data'
# BASE_DIR = '../Data'
paths = {
    'meta':        f"{BASE_DIR}/Source C-D-E-F/Input files/119th_Congress_20250809.csv",
    'A':           f"{BASE_DIR}/Source A-B/Output files/bridge_grade_source_a_cross_party_supported_bills.csv",
    'B':           f"{BASE_DIR}/Source A-B/Output files/bridge_grade_source_b_cross_party_cosponsors.csv",
    'CDEF':        f"{BASE_DIR}/Source C-D-E-F/Output files/bridge_grades_source_cdef_app_communication.csv",
    'M_House':     f"{BASE_DIR}/Source M/Output files/bridge_grade_source_m_house_pvi.csv",
    'M_Senate':    f"{BASE_DIR}/Source M/Output files/bridge_grade_source_m_senate_pvi.csv",
    'N_House':     f"{BASE_DIR}/Source N/Output files/bridge_grade_source_n_house_ideology.csv",
    'N_Senate':    f"{BASE_DIR}/Source N/Output files/bridge_grade_source_n_senate_ideology.csv",
    'P':           f"{BASE_DIR}/Source P/problem_solvers.csv",
}

# Load raw APP profiles (attendance data)
source_APP_profiles = pd.read_csv(
    f"{BASE_DIR}/profiles.csv",
    usecols=['full_name','bioguide_id','attendance_total','attendance_max']
)

# Check each file exists
missing_files = [key for key, p in paths.items() if not os.path.exists(p)]
if missing_files:
    raise FileNotFoundError(f"Missing input files for sources: {missing_files}")
print("All input files found.")

Load DataFrames & Validate Weights#

We load each CSV into a DataFrame and then ensure the set of weight keys matches the loaded source labels exactly.

# Load master metadata
meta_data        = pd.read_csv(paths['meta'])

# Load each source DataFrame
source_A         = pd.read_csv(paths['A'])
source_B         = pd.read_csv(paths['B'])
source_APP       = pd.read_csv(paths['CDEF'])
source_M_House   = pd.read_csv(paths['M_House'])
source_M_Senate  = pd.read_csv(paths['M_Senate'])
source_N_House   = pd.read_csv(paths['N_House'])
source_N_Senate  = pd.read_csv(paths['N_Senate'])
source_P         = pd.read_csv(paths['P'])

# 2.3 Verify weight keys vs. sources to be scored (A–O)
loaded_sources = set(weights.keys())
expected_sources = {'A','B','C','D','E','F'}
if loaded_sources != expected_sources:
    raise ValueError(
        f"Weights keys {loaded_sources} do not match expected {expected_sources}"
    )

print("Weights validated against source labels.")

Weights validated against source labels.

Build Base Member Tables#

In this section we initialize our working DataFrames for the House and Senate by subsetting the master meta_data. These tables will be the foundation for merging each source’s metrics.

# Preview master metadata
meta_data.head(10)

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	start_year	end_year	update_date	image_url
0	M001233	Mark B. Messmer	Mark	B.	Messmer	NaN	House	Indiana	8.0	Republican	2025	NaN	2025-07-14T14:25:50Z	https://www.congress.gov/img/member/677448630b...
1	R000617	Delia C. Ramirez	Delia	C.	Ramirez	NaN	House	Illinois	3.0	Democratic	2023	NaN	2025-06-13T13:48:04Z	https://www.congress.gov/img/member/684c235633...
2	S001232	Tim Sheehy	Tim	NaN	Sheehy	NaN	Senate	Montana	NaN	Republican	2025	NaN	2025-06-07T10:30:29Z	https://www.congress.gov/img/member/677d8231fd...
3	L000570	Ben Ray Luján	Ben	Ray	Luján	NaN	Senate	New Mexico	NaN	Democratic	2021	NaN	2025-06-03T13:18:42Z	https://www.congress.gov/img/member/l000570_20...
4	H001089	Josh Hawley	Josh	NaN	Hawley	NaN	Senate	Missouri	NaN	Republican	2019	NaN	2025-05-28T10:30:24Z	https://www.congress.gov/img/member/h001089_20...
5	W000800	Peter Welch	Peter	NaN	Welch	NaN	Senate	Vermont	NaN	Democratic	2023	NaN	2025-05-24T10:30:30Z	https://www.congress.gov/img/member/fd3cb364b8...
6	M001242	Bernie Moreno	Bernie	NaN	Moreno	NaN	Senate	Ohio	NaN	Republican	2025	NaN	2025-05-17T10:30:27Z	https://www.congress.gov/img/member/67c8694e61...
7	M001229	LaMonica McIver	LaMonica	NaN	McIver	NaN	House	New Jersey	10.0	Democratic	2024	NaN	2025-05-09T13:45:32Z	https://www.congress.gov/img/member/681dfed94f...
8	H001085	Chrissy Houlahan	Chrissy	NaN	Houlahan	NaN	House	Pennsylvania	6.0	Democratic	2019	NaN	2025-05-08T13:36:39Z	https://www.congress.gov/img/member/681bc0e6b7...
9	M001244	Ashley Moody	Ashley	NaN	Moody	NaN	Senate	Florida	NaN	Republican	2025	NaN	2025-05-07T10:42:23Z	No Image Available

# Subset to House members
house_final = meta_data.query("Chamber=='House'").copy()
print(house_final.shape[0])
house_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	start_year	end_year	update_date	image_url
0	M001233	Mark B. Messmer	Mark	B.	Messmer	NaN	House	Indiana	8.0	Republican	2025	NaN	2025-07-14T14:25:50Z	https://www.congress.gov/img/member/677448630b...
1	R000617	Delia C. Ramirez	Delia	C.	Ramirez	NaN	House	Illinois	3.0	Democratic	2023	NaN	2025-06-13T13:48:04Z	https://www.congress.gov/img/member/684c235633...
7	M001229	LaMonica McIver	LaMonica	NaN	McIver	NaN	House	New Jersey	10.0	Democratic	2024	NaN	2025-05-09T13:45:32Z	https://www.congress.gov/img/member/681dfed94f...
8	H001085	Chrissy Houlahan	Chrissy	NaN	Houlahan	NaN	House	Pennsylvania	6.0	Democratic	2019	NaN	2025-05-08T13:36:39Z	https://www.congress.gov/img/member/681bc0e6b7...
10	M001226	Robert Menendez	Robert	NaN	Menendez	NaN	House	New Jersey	8.0	Democratic	2023	NaN	2025-04-30T18:14:58Z	https://www.congress.gov/img/member/681231f624...

# Subset to Senate members
senate_final = meta_data.query("Chamber=='Senate'").copy()
print(senate_final.shape[0])
senate_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	start_year	end_year	update_date	image_url
2	S001232	Tim Sheehy	Tim	NaN	Sheehy	NaN	Senate	Montana	NaN	Republican	2025	NaN	2025-06-07T10:30:29Z	https://www.congress.gov/img/member/677d8231fd...
3	L000570	Ben Ray Luján	Ben	Ray	Luján	NaN	Senate	New Mexico	NaN	Democratic	2021	NaN	2025-06-03T13:18:42Z	https://www.congress.gov/img/member/l000570_20...
4	H001089	Josh Hawley	Josh	NaN	Hawley	NaN	Senate	Missouri	NaN	Republican	2019	NaN	2025-05-28T10:30:24Z	https://www.congress.gov/img/member/h001089_20...
5	W000800	Peter Welch	Peter	NaN	Welch	NaN	Senate	Vermont	NaN	Democratic	2023	NaN	2025-05-24T10:30:30Z	https://www.congress.gov/img/member/fd3cb364b8...
6	M001242	Bernie Moreno	Bernie	NaN	Moreno	NaN	Senate	Ohio	NaN	Republican	2025	NaN	2025-05-17T10:30:27Z	https://www.congress.gov/img/member/67c8694e61...

Attendance Filtering#

Legislators below the minimum attendance threshold (att_pct) are excluded from scoring. We calculate each member’s attendance percentage and remove those below att_pct.

# Extract attendance data
source_att = source_APP_profiles[[
    'full_name','bioguide_id','attendance_total','attendance_max'
]].copy()
source_att.head()

	full_name	bioguide_id	attendance_total	attendance_max
0	Maria Cantwell	C000127	414.0	414
1	Amy Klobuchar	K000367	410.0	414
2	Bernard Sanders	S000033	371.0	414
3	Sheldon Whitehouse	W000802	393.0	414
4	John Barrasso	B001261	411.0	414

source_att[source_att['attendance_total'].isna()]

	full_name	bioguide_id	attendance_total	attendance_max
210	Aumua Amata Radewagen	R000600	NaN	168
500	Kimberlyn King-Hinds	K000404	NaN	168
520	Pablo José Hernández Rivera	H001103	NaN	168

# Note, missing legislators are non-voting members from territories.

# Fill missing totals with zero
source_att['attendance_total'] = source_att['attendance_total'].fillna(0)

# Compute attendance percentage
source_att['attendance_pct'] = (
    source_att['attendance_total'] / source_att['attendance_max']
)

# Identify members below threshold
low_att = source_att.query("attendance_pct < @att_pct").drop_duplicates(subset='bioguide_id')
low_att

	full_name	bioguide_id	attendance_total	attendance_max	attendance_pct
95	Eleanor Norton	N000147	4.0	168	0.023810
207	Stacey Plaskett	P000610	7.0	168	0.041667
210	Aumua Amata Radewagen	R000600	0.0	168	0.000000
405	James (Jim) Moylan	M001219	6.0	168	0.035714
500	Kimberlyn King-Hinds	K000404	0.0	168	0.000000
520	Pablo José Hernández Rivera	H001103	0.0	168	0.000000

## Note: all of the legislators with low attendance are non-voting members from territories, so this makes sense!

# Remove low‐attendance members from both tables
to_remove = set(low_att['bioguide_id'])
house_final = house_final[~house_final['bioguide_id'].isin(to_remove)].copy()
senate_final = senate_final[~senate_final['bioguide_id'].isin(to_remove)].copy()

print(house_final.shape[0]) # total number of members in the house
print(senate_final.shape[0]) # total number of members in the senate

431
100

Source A: Authors of Bills with Cross-Party Sponsors#

Rewards Members of the 119th U.S. Congress for sponsoring legislation that attracted at least one cosponsor from the opposite party. We take each legislator’s total count of such bills, fill true “no-activity” values with zeros, and convert counts into a 0–100 percentile score.

Data origin: OpenStates bill sponsorship CSV for the 119th Congress
Download link: https://open.pluralpolicy.com/data/session-csv/
Date downloaded: August 8, 2025
Preprocessing notebook: “Source A – B: Legislator and Sponsorship Data”

Why fill with zeros?
A missing count indicates the legislator had no cross-party bills. Zero appropriately reflects “no activity,” not unknown data.

Load & Prepare Source A#

# Select only the primary bioguide ID and cross-party bill count
source_A = source_A[['primary_bioguide_id', 'num_bills_with_cross_party_cosponsors']].copy()
assert {'primary_bioguide_id','num_bills_with_cross_party_cosponsors'} <= set(source_A.columns), \
    "Unexpected columns in source_A"
source_A.head()

	primary_bioguide_id	num_bills_with_cross_party_cosponsors
0	K000367	51
1	C001075	49
2	C001056	48
3	G000386	43
4	F000466	42

Merge & Normalize for House#

# Merge into house_final by bioguide_id
house_final = house_final.merge(
    source_A.rename(columns={'primary_bioguide_id':'bioguide_id'}),
    on='bioguide_id',
    how='left'
)

# Check raw data to see if true
house_final[house_final[
    'num_bills_with_cross_party_cosponsors'].isna()]

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	start_year	end_year	update_date	image_url	num_bills_with_cross_party_cosponsors
10	J000299	Mike Johnson	Mike	NaN	Johnson	NaN	House	Louisiana	4.0	Republican	2017	NaN	2025-04-28T13:05:21Z	https://www.congress.gov/img/member/67ffcb2af2...	NaN
257	F000110	Cleo Fields	Cleo	NaN	Fields	NaN	House	Louisiana	6.0	Democratic	2025	NaN	2025-04-28T13:04:20Z	https://www.congress.gov/img/member/677426250b...	NaN
258	H000874	Steny H. Hoyer	Steny	H.	Hoyer	NaN	House	Maryland	5.0	Democratic	1981	NaN	2025-04-28T13:04:20Z	https://www.congress.gov/img/member/116_rp_md_...	NaN
301	G000586	Jesús G. "Chuy" García	Jesús	G.	García	Chuy	House	Illinois	4.0	Democratic	2019	NaN	2025-04-28T13:04:18Z	https://www.congress.gov/img/member/g000586_20...	NaN
424	P000197	Nancy Pelosi	Nancy	NaN	Pelosi	NaN	House	California	11.0	Democratic	1987	NaN	2025-04-28T13:04:14Z	https://www.congress.gov/img/member/p000197_20...	NaN

Note

Mike Johson (speaker, republican)
Hakeem Jeffries (democratic minority leader)
Nancy Pelosi (speaker emerita) likely are not doing a lot of bill sponsorship in general, so this makes sense
Steney Hoyer, might be close to retirement, so this makes sense
Chuy Garcia and Greg Casar very progressive, but still double check
Cleo Fields worth double checking

# Fill missing counts (no cross-party bills) with zero
house_final['num_bills_with_cross_party_cosponsors'] = house_final[
    'num_bills_with_cross_party_cosponsors'
].fillna(0)

# Normalize A House
house_final['A: num_bills_with_cross_party_cosponsors'] = \
    house_final['num_bills_with_cross_party_cosponsors']


# Recalculate mean and std
mean_A = house_final['num_bills_with_cross_party_cosponsors'].mean()
std_A = house_final['num_bills_with_cross_party_cosponsors'].std()

# Add normalized column
house_final['norm_A'] = norm.cdf(house_final['num_bills_with_cross_party_cosponsors'], mean_A, std_A) * 100

# Clean up
house_final.drop(columns=['num_bills_with_cross_party_cosponsors'], inplace=True)
house_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	start_year	end_year	update_date	image_url	A: num_bills_with_cross_party_cosponsors	norm_A
0	M001233	Mark B. Messmer	Mark	B.	Messmer	NaN	House	Indiana	8.0	Republican	2025	NaN	2025-07-14T14:25:50Z	https://www.congress.gov/img/member/677448630b...	1.0	20.874310
1	R000617	Delia C. Ramirez	Delia	C.	Ramirez	NaN	House	Illinois	3.0	Democratic	2023	NaN	2025-06-13T13:48:04Z	https://www.congress.gov/img/member/684c235633...	1.0	20.874310
2	M001229	LaMonica McIver	LaMonica	NaN	McIver	NaN	House	New Jersey	10.0	Democratic	2024	NaN	2025-05-09T13:45:32Z	https://www.congress.gov/img/member/681dfed94f...	1.0	20.874310
3	H001085	Chrissy Houlahan	Chrissy	NaN	Houlahan	NaN	House	Pennsylvania	6.0	Democratic	2019	NaN	2025-05-08T13:36:39Z	https://www.congress.gov/img/member/681bc0e6b7...	15.0	96.832815
4	M001226	Robert Menendez	Robert	NaN	Menendez	NaN	House	New Jersey	8.0	Democratic	2023	NaN	2025-04-30T18:14:58Z	https://www.congress.gov/img/member/681231f624...	2.0	26.754660

Merge & Normalize for Senate#

# Merge into senate_final by bioguide_id
senate_final = senate_final.merge(
    source_A.rename(columns={'primary_bioguide_id':'bioguide_id'}),
    on='bioguide_id',
    how='left'
)

# Check raw data to see if true
senate_final[senate_final[
    'num_bills_with_cross_party_cosponsors'].isna()]

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	start_year	end_year	update_date	image_url	num_bills_with_cross_party_cosponsors

## Note: No missing values in Senate

# Fill missing counts with zero
senate_final['num_bills_with_cross_party_cosponsors'] = senate_final[
    'num_bills_with_cross_party_cosponsors'
].fillna(0)

# Normalize A - Senate
senate_final['A: num_bills_with_cross_party_cosponsors'] = \
    senate_final['num_bills_with_cross_party_cosponsors']

# Recalculate mean and std
mean_A = senate_final['num_bills_with_cross_party_cosponsors'].mean()
std_A = senate_final['num_bills_with_cross_party_cosponsors'].std()

# Add normalized column
senate_final['norm_A'] = norm.cdf(senate_final['num_bills_with_cross_party_cosponsors'], mean_A, std_A) * 100

# Drop duplicates and cleanup
senate_final.drop_duplicates(subset='bioguide_id', inplace=True)
senate_final.drop(columns=['num_bills_with_cross_party_cosponsors'], inplace=True)
senate_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	start_year	end_year	update_date	image_url	A: num_bills_with_cross_party_cosponsors	norm_A
0	S001232	Tim Sheehy	Tim	NaN	Sheehy	NaN	Senate	Montana	NaN	Republican	2025	NaN	2025-06-07T10:30:29Z	https://www.congress.gov/img/member/677d8231fd...	6	24.239891
1	L000570	Ben Ray Luján	Ben	Ray	Luján	NaN	Senate	New Mexico	NaN	Democratic	2021	NaN	2025-06-03T13:18:42Z	https://www.congress.gov/img/member/l000570_20...	8	30.450752
3	H001089	Josh Hawley	Josh	NaN	Hawley	NaN	Senate	Missouri	NaN	Republican	2019	NaN	2025-05-28T10:30:24Z	https://www.congress.gov/img/member/h001089_20...	13	48.258655
4	W000800	Peter Welch	Peter	NaN	Welch	NaN	Senate	Vermont	NaN	Democratic	2023	NaN	2025-05-24T10:30:30Z	https://www.congress.gov/img/member/fd3cb364b8...	15	55.703808
5	M001242	Bernie Moreno	Bernie	NaN	Moreno	NaN	Senate	Ohio	NaN	Republican	2025	NaN	2025-05-17T10:30:27Z	https://www.congress.gov/img/member/67c8694e61...	3	16.371664

Source B: Ranked People Who Cosponsor Bills#

This section processes Source B, which rewards Members of the 119th U.S. Congress for cosponsoring bills authored by another party. We take each legislator’s total count of such cross-party cosponsorships, fill true zero-activity values with zeros, and convert counts into a 0–100 percentile score.

Data origin: OpenStates bill sponsorship CSV for the 119th Congress
Download link: https://open.pluralpolicy.com/data/session-csv/
Date downloaded: August 8, 2025
Preprocessing notebook: “Source A – B: Legislator and Sponsorship Data”
Note: Missing values (no cross-party cosponsorships) are filled with 0

Why fill with zeros?
A missing count indicates the legislator did not cosponsor any cross-party bills. Zero correctly represents “no activity.”

Load & Prepare Source B#

# Select only bioguide_id and cosponsor count, then copy
assert {'bioguide_id','num_cross_party_cosponsored_bills'} <= set(source_B.columns), \
    "Unexpected columns in source_B"
source_B = source_B[['bioguide_id','num_cross_party_cosponsored_bills']].copy()
source_B.head(3)

	bioguide_id	num_cross_party_cosponsored_bills
0	F000466	433
1	D000230	240
2	P000613	167

Merge & Normalize for House#

# Merge into house_final by bioguide_id
house_final = house_final.merge(
    source_B,
    on='bioguide_id',
    how='left'
)

house_final[house_final[
    'num_cross_party_cosponsored_bills'].isna()]

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	start_year	end_year	update_date	image_url	A: num_bills_with_cross_party_cosponsors	norm_A	num_cross_party_cosponsored_bills

## Note: No missing values for the house

# Fill missing counts with zero
house_final['num_cross_party_cosponsored_bills'] = \
    house_final['num_cross_party_cosponsored_bills'].fillna(0)

# Normalize B - House

# # Compute CDF percentile
house_final['B: num_cross_party_cosponsored_bills'] = \
    house_final['num_cross_party_cosponsored_bills']

# Recalculate mean and std
mean_B = house_final['num_cross_party_cosponsored_bills'].mean()
std_B = house_final['num_cross_party_cosponsored_bills'].std()

# Add normalized column
house_final['norm_B'] = norm.cdf(house_final['num_cross_party_cosponsored_bills'], mean_B, std_B) * 100

# Clean up raw column
house_final.drop(columns=['num_cross_party_cosponsored_bills'], inplace=True)
house_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	start_year	end_year	update_date	image_url	A: num_bills_with_cross_party_cosponsors	norm_A	B: num_cross_party_cosponsored_bills	norm_B
0	M001233	Mark B. Messmer	Mark	B.	Messmer	NaN	House	Indiana	8.0	Republican	2025	NaN	2025-07-14T14:25:50Z	https://www.congress.gov/img/member/677448630b...	1.0	20.874310	6	27.624352
1	R000617	Delia C. Ramirez	Delia	C.	Ramirez	NaN	House	Illinois	3.0	Democratic	2023	NaN	2025-06-13T13:48:04Z	https://www.congress.gov/img/member/684c235633...	1.0	20.874310	19	41.338114
2	M001229	LaMonica McIver	LaMonica	NaN	McIver	NaN	House	New Jersey	10.0	Democratic	2024	NaN	2025-05-09T13:45:32Z	https://www.congress.gov/img/member/681dfed94f...	1.0	20.874310	17	39.105279
3	H001085	Chrissy Houlahan	Chrissy	NaN	Houlahan	NaN	House	Pennsylvania	6.0	Democratic	2019	NaN	2025-05-08T13:36:39Z	https://www.congress.gov/img/member/681bc0e6b7...	15.0	96.832815	73	90.981076
4	M001226	Robert Menendez	Robert	NaN	Menendez	NaN	House	New Jersey	8.0	Democratic	2023	NaN	2025-04-30T18:14:58Z	https://www.congress.gov/img/member/681231f624...	2.0	26.754660	14	35.824398

Merge & Normalize for Senate#

# Merge into senate_final by bioguide_id
senate_final = senate_final.merge(
    source_B,
    on='bioguide_id',
    how='left'
)

senate_final[senate_final[
    'num_cross_party_cosponsored_bills'].isna()]

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	start_year	end_year	update_date	image_url	A: num_bills_with_cross_party_cosponsors	norm_A	num_cross_party_cosponsored_bills

## Note: No missing values for the Senate

# Fill missing counts with zero
senate_final['num_cross_party_cosponsored_bills'] = \
    senate_final['num_cross_party_cosponsored_bills'].fillna(0)

# Normalize B - Senate
senate_final['B: num_cross_party_cosponsored_bills'] = \
    senate_final['num_cross_party_cosponsored_bills']


# Recalculate mean and std
mean_B = senate_final['num_cross_party_cosponsored_bills'].mean()
std_B = senate_final['num_cross_party_cosponsored_bills'].std()

# Add normalized column
senate_final['norm_B'] = norm.cdf(senate_final['num_cross_party_cosponsored_bills'], mean_B, std_B) * 100

# Drop duplicate legislators and cleanup
senate_final.drop_duplicates(subset='bioguide_id', inplace=True)
senate_final.drop(columns=['num_cross_party_cosponsored_bills'], inplace=True)
senate_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	start_year	end_year	update_date	image_url	A: num_bills_with_cross_party_cosponsors	norm_A	B: num_cross_party_cosponsored_bills	norm_B
0	S001232	Tim Sheehy	Tim	NaN	Sheehy	NaN	Senate	Montana	NaN	Republican	2025	NaN	2025-06-07T10:30:29Z	https://www.congress.gov/img/member/677d8231fd...	6	24.239891	24	29.006544
1	L000570	Ben Ray Luján	Ben	Ray	Luján	NaN	Senate	New Mexico	NaN	Democratic	2021	NaN	2025-06-03T13:18:42Z	https://www.congress.gov/img/member/l000570_20...	8	30.450752	57	75.553948
3	H001089	Josh Hawley	Josh	NaN	Hawley	NaN	Senate	Missouri	NaN	Republican	2019	NaN	2025-05-28T10:30:24Z	https://www.congress.gov/img/member/h001089_20...	13	48.258655	21	25.257922
4	W000800	Peter Welch	Peter	NaN	Welch	NaN	Senate	Vermont	NaN	Democratic	2023	NaN	2025-05-24T10:30:30Z	https://www.congress.gov/img/member/fd3cb364b8...	15	55.703808	63	82.080297
5	M001242	Bernie Moreno	Bernie	NaN	Moreno	NaN	Senate	Ohio	NaN	Republican	2025	NaN	2025-05-17T10:30:27Z	https://www.congress.gov/img/member/67c8694e61...	3	16.371664	13	16.645559

Source C: Communication – Bipartisanship (Sum)#

Rewards Members of the 119th U.S. Congress for communications that support members of the opposite party. We count each legislator’s total outcome_bipartisanship flags, fill true zero‐activity with zeros, and convert counts into a 0–100 percentile score.

Data origin: American Political Pulse communications CSV (2025 download)
Download link: https://americaspoliticalpulse.com/data/ (Download “US officials – 2025”)
Date downloaded: August 8, 2025
Preprocessing notebook: Source C–D–E–F: App_Communications_Calculations

Why fill with zeros?
A missing outcome_bipartisanship value means the legislator made no bipartisan supportive communications. Zero accurately indicates “none.”

Load & Prepare Source C#

# Ensure expected column exists
assert 'outcome_bipartisanship' in source_APP.columns, "Missing 'outcome_bipartisanship' in source_APP"

# Subset and copy
source_C = source_APP[['bioguide_id','outcome_bipartisanship']].copy()
source_C.head()

	bioguide_id	outcome_bipartisanship
0	A000055	10.0
1	A000148	99.0
2	A000369	20.0
3	A000370	12.0
4	A000371	3.0

# Merge into house_final
house_final = house_final.merge(
    source_C,
    on='bioguide_id',
    how='left'
)

house_final[house_final[
    'outcome_bipartisanship'].isna()]

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	start_year	end_year	update_date	image_url	A: num_bills_with_cross_party_cosponsors	norm_A	B: num_cross_party_cosponsored_bills	norm_B	outcome_bipartisanship

## Note: No missing values for house

# Fill missing with zero
house_final['outcome_bipartisanship'] = \
    house_final['outcome_bipartisanship'].fillna(0)

# Normalize C - House
house_final['C: outcome_bipartisanship'] = \
    house_final['outcome_bipartisanship']

# Recalculate mean and std
mean_C = house_final['outcome_bipartisanship'].mean()
std_C = house_final['outcome_bipartisanship'].std()

# Add normalized column
house_final['norm_C'] = norm.cdf(house_final['outcome_bipartisanship'], mean_C, std_C) * 100

# Drop raw column and remove any duplicates
house_final.drop(columns=['outcome_bipartisanship'], inplace=True)
if house_final['bioguide_id'].duplicated().any():
    house_final.drop_duplicates(subset='bioguide_id', inplace=True)

house_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	start_year	end_year	update_date	image_url	A: num_bills_with_cross_party_cosponsors	norm_A	B: num_cross_party_cosponsored_bills	norm_B	C: outcome_bipartisanship	norm_C
0	M001233	Mark B. Messmer	Mark	B.	Messmer	NaN	House	Indiana	8.0	Republican	2025	NaN	2025-07-14T14:25:50Z	https://www.congress.gov/img/member/677448630b...	1.0	20.874310	6	27.624352	2.0	15.141404
1	R000617	Delia C. Ramirez	Delia	C.	Ramirez	NaN	House	Illinois	3.0	Democratic	2023	NaN	2025-06-13T13:48:04Z	https://www.congress.gov/img/member/684c235633...	1.0	20.874310	19	41.338114	28.0	39.575556
2	M001229	LaMonica McIver	LaMonica	NaN	McIver	NaN	House	New Jersey	10.0	Democratic	2024	NaN	2025-05-09T13:45:32Z	https://www.congress.gov/img/member/681dfed94f...	1.0	20.874310	17	39.105279	8.0	19.666071
3	H001085	Chrissy Houlahan	Chrissy	NaN	Houlahan	NaN	House	Pennsylvania	6.0	Democratic	2019	NaN	2025-05-08T13:36:39Z	https://www.congress.gov/img/member/681bc0e6b7...	15.0	96.832815	73	90.981076	60.0	75.126253
4	M001226	Robert Menendez	Robert	NaN	Menendez	NaN	House	New Jersey	8.0	Democratic	2023	NaN	2025-04-30T18:14:58Z	https://www.congress.gov/img/member/681231f624...	2.0	26.754660	14	35.824398	36.0	48.857402

Merge & Normalize for Senate#

# Merge into senate_final
senate_final = senate_final.merge(
    source_C,
    on='bioguide_id',
    how='left'
)

senate_final[senate_final[
    'outcome_bipartisanship'].isna()]

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	start_year	end_year	update_date	image_url	A: num_bills_with_cross_party_cosponsors	norm_A	B: num_cross_party_cosponsored_bills	norm_B	outcome_bipartisanship

## Note: No missing values for Senate

# Fill missing with zero
senate_final['outcome_bipartisanship'] = \
    senate_final['outcome_bipartisanship'].fillna(0)

# Normalize C - Senate
senate_final['C: outcome_bipartisanship'] = \
    senate_final['outcome_bipartisanship']

# Recalculate mean and std
mean_C = senate_final['outcome_bipartisanship'].mean()
std_C = senate_final['outcome_bipartisanship'].std()

# Add normalized column
senate_final['norm_C'] = norm.cdf(senate_final['outcome_bipartisanship'], mean_C, std_C) * 100

# Clean up
if senate_final['bioguide_id'].duplicated().any():
    senate_final.drop_duplicates(subset='bioguide_id', inplace=True)
senate_final.drop(columns=['outcome_bipartisanship'], inplace=True)

senate_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	start_year	end_year	update_date	image_url	A: num_bills_with_cross_party_cosponsors	norm_A	B: num_cross_party_cosponsored_bills	norm_B	C: outcome_bipartisanship	norm_C
0	S001232	Tim Sheehy	Tim	NaN	Sheehy	NaN	Senate	Montana	NaN	Republican	2025	NaN	2025-06-07T10:30:29Z	https://www.congress.gov/img/member/677d8231fd...	6	24.239891	24	29.006544	2.0	11.809128
1	L000570	Ben Ray Luján	Ben	Ray	Luján	NaN	Senate	New Mexico	NaN	Democratic	2021	NaN	2025-06-03T13:18:42Z	https://www.congress.gov/img/member/l000570_20...	8	30.450752	57	75.553948	76.0	38.604383
2	H001089	Josh Hawley	Josh	NaN	Hawley	NaN	Senate	Missouri	NaN	Republican	2019	NaN	2025-05-28T10:30:24Z	https://www.congress.gov/img/member/h001089_20...	13	48.258655	21	25.257922	9.0	13.568212
3	W000800	Peter Welch	Peter	NaN	Welch	NaN	Senate	Vermont	NaN	Democratic	2023	NaN	2025-05-24T10:30:30Z	https://www.congress.gov/img/member/fd3cb364b8...	15	55.703808	63	82.080297	198.0	88.214775
4	M001242	Bernie Moreno	Bernie	NaN	Moreno	NaN	Senate	Ohio	NaN	Republican	2025	NaN	2025-05-17T10:30:27Z	https://www.congress.gov/img/member/67c8694e61...	3	16.371664	13	16.645559	39.0	23.052655

Source D: Communication – Bipartisanship (Mean)#

Rewards Members of the 119th U.S. Congress for the proportion of their communications that are supportive of the opposite party. We take each legislator’s percentage (outcome_bipartisanship_pct), fill true zero‐activity values with zeros, and convert percentages into a percentile score using median & MAD.

Data origin: American Political Pulse communications CSV (2025 download)
Download link: https://americaspoliticalpulse.com/data/ (Download “US officials – 2025”)
Date downloaded: August 8, 2025
Preprocessing notebook: Source C–D–E–F: App_Communications_Calculations

Why fill with zeros?
A missing percentage means the legislator made no bipartisan communications—zero accurately reflects “none.”

Load & Prepare Source D#

# Validate expected column
assert 'outcome_bipartisanship_pct' in source_APP.columns, \
    "Missing 'outcome_bipartisanship_pct' in source_APP"

# Subset and copy
source_D = source_APP[['bioguide_id','outcome_bipartisanship_pct']].copy()
source_D.head()

	bioguide_id	outcome_bipartisanship_pct
0	A000055	3.906250
1	A000148	10.963455
2	A000369	6.944444
3	A000370	4.210526
4	A000371	2.439024

# Merge into house_final
house_final = house_final.merge(
    source_D,
    on='bioguide_id',
    how='left'
)

house_final[house_final[
    'outcome_bipartisanship_pct'].isna()]

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	...	end_year	update_date	image_url	A: num_bills_with_cross_party_cosponsors	norm_A	B: num_cross_party_cosponsored_bills	norm_B	C: outcome_bipartisanship	norm_C	outcome_bipartisanship_pct

0 rows × 21 columns

### Note: No missing values for House

# Fill missing percentages with zero
house_final['outcome_bipartisanship_pct'] = \
    house_final['outcome_bipartisanship_pct'].fillna(0)

# Normalize D - House
house_final['D: outcome_bipartisanship_pct'] = \
    house_final['outcome_bipartisanship_pct']

# Recalculate mean and std
mean_D = house_final['outcome_bipartisanship_pct'].mean()
std_D = house_final['outcome_bipartisanship_pct'].std()

# Add normalized column
house_final['norm_D'] = norm.cdf(house_final['outcome_bipartisanship_pct'], mean_D, std_D) * 100

# Cleanup
house_final.drop(columns=['outcome_bipartisanship_pct'], inplace=True)
if house_final['bioguide_id'].duplicated().any():
    house_final.drop_duplicates(subset='bioguide_id', inplace=True)

house_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	...	update_date	image_url	A: num_bills_with_cross_party_cosponsors	norm_A	B: num_cross_party_cosponsored_bills	norm_B	C: outcome_bipartisanship	norm_C	D: outcome_bipartisanship_pct	norm_D
0	M001233	Mark B. Messmer	Mark	B.	Messmer	NaN	House	Indiana	8.0	Republican	...	2025-07-14T14:25:50Z	https://www.congress.gov/img/member/677448630b...	1.0	20.874310	6	27.624352	2.0	15.141404	4.878049	43.384639
1	R000617	Delia C. Ramirez	Delia	C.	Ramirez	NaN	House	Illinois	3.0	Democratic	...	2025-06-13T13:48:04Z	https://www.congress.gov/img/member/684c235633...	1.0	20.874310	19	41.338114	28.0	39.575556	1.842105	15.378290
2	M001229	LaMonica McIver	LaMonica	NaN	McIver	NaN	House	New Jersey	10.0	Democratic	...	2025-05-09T13:45:32Z	https://www.congress.gov/img/member/681dfed94f...	1.0	20.874310	17	39.105279	8.0	19.666071	5.095541	45.801824
3	H001085	Chrissy Houlahan	Chrissy	NaN	Houlahan	NaN	House	Pennsylvania	6.0	Democratic	...	2025-05-08T13:36:39Z	https://www.congress.gov/img/member/681bc0e6b7...	15.0	96.832815	73	90.981076	60.0	75.126253	7.633588	72.850883
4	M001226	Robert Menendez	Robert	NaN	Menendez	NaN	House	New Jersey	8.0	Democratic	...	2025-04-30T18:14:58Z	https://www.congress.gov/img/member/681231f624...	2.0	26.754660	14	35.824398	36.0	48.857402	4.411765	38.295997

5 rows × 22 columns

Merge & Normalize for Senate#

# Merge into house_final
senate_final = senate_final.merge(
    source_D,
    on='bioguide_id',
    how='left'
)

senate_final[senate_final[
    'outcome_bipartisanship_pct'].isna()]

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	...	end_year	update_date	image_url	A: num_bills_with_cross_party_cosponsors	norm_A	B: num_cross_party_cosponsored_bills	norm_B	C: outcome_bipartisanship	norm_C	outcome_bipartisanship_pct

0 rows × 21 columns

## Note: No missing values for Senate

# Fill missing percentages with zero
senate_final['outcome_bipartisanship_pct'] = \
    senate_final['outcome_bipartisanship_pct'].fillna(0)

# Normalize D - Senate
senate_final['D: outcome_bipartisanship_pct'] = \
    senate_final['outcome_bipartisanship_pct']

# Recalculate mean and std
mean_D = senate_final['outcome_bipartisanship_pct'].mean()
std_D = senate_final['outcome_bipartisanship_pct'].std()

# Add normalized column
senate_final['norm_D'] = norm.cdf(senate_final['outcome_bipartisanship_pct'], mean_D, std_D) * 100

# Cleanup
senate_final.drop(columns=['outcome_bipartisanship_pct'], inplace=True)
if senate_final['bioguide_id'].duplicated().any():
    senate_final.drop_duplicates(subset='bioguide_id', inplace=True)

senate_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	...	update_date	image_url	A: num_bills_with_cross_party_cosponsors	norm_A	B: num_cross_party_cosponsored_bills	norm_B	C: outcome_bipartisanship	norm_C	D: outcome_bipartisanship_pct	norm_D
0	S001232	Tim Sheehy	Tim	NaN	Sheehy	NaN	Senate	Montana	NaN	Republican	...	2025-06-07T10:30:29Z	https://www.congress.gov/img/member/677d8231fd...	6	24.239891	24	29.006544	2.0	11.809128	4.000000	19.172695
1	L000570	Ben Ray Luján	Ben	Ray	Luján	NaN	Senate	New Mexico	NaN	Democratic	...	2025-06-03T13:18:42Z	https://www.congress.gov/img/member/l000570_20...	8	30.450752	57	75.553948	76.0	38.604383	6.959707	47.529597
2	H001089	Josh Hawley	Josh	NaN	Hawley	NaN	Senate	Missouri	NaN	Republican	...	2025-05-28T10:30:24Z	https://www.congress.gov/img/member/h001089_20...	13	48.258655	21	25.257922	9.0	13.568212	2.719033	11.086503
3	W000800	Peter Welch	Peter	NaN	Welch	NaN	Senate	Vermont	NaN	Democratic	...	2025-05-24T10:30:30Z	https://www.congress.gov/img/member/fd3cb364b8...	15	55.703808	63	82.080297	198.0	88.214775	6.954689	47.474948
4	M001242	Bernie Moreno	Bernie	NaN	Moreno	NaN	Senate	Ohio	NaN	Republican	...	2025-05-17T10:30:27Z	https://www.congress.gov/img/member/67c8694e61...	3	16.371664	13	16.645559	39.0	23.052655	6.280193	40.213106

5 rows × 22 columns

Source E: Attack_Personal (Sum)#

Penalizes Members of the 119th U.S. Congress for communications classified as personal attacks. We count each legislator’s total attack_personal flags, fill true zero‐activity values with zeros, and convert into an inverse normalized score—higher attack counts yield lower scores.

Data origin: American Political Pulse communications CSV (2025 download)
Download link: https://americaspoliticalpulse.com/data/ (Download “US officials – 2025”)
Date downloaded: August 8, 2025
Preprocessing notebook: Source C–D–E–F: App_Communications_Calculations

Why fill with zeros?
A missing attack_personal means the legislator made no personal attacks. Zero accurately represents “none.”

Normalized Score
We apply 1 – CDF so that more attacks → lower percentile score (0–100).

Load & Prepare Source E#

# Validate and subset
assert 'attack_personal' in source_APP.columns, "Missing 'attack_personal' in source_APP"
source_E = source_APP[['bioguide_id','attack_personal']].copy()
source_E.head()

	bioguide_id	attack_personal
0	A000055	3.0
1	A000148	76.0
2	A000369	1.0
3	A000370	3.0
4	A000371	4.0

Merge & Normalize for House#

# Merge into house_final
house_final = house_final.merge(
    source_E,
    on='bioguide_id',
    how='left'
)

house_final[house_final[
    'attack_personal'].isna()]

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	...	image_url	A: num_bills_with_cross_party_cosponsors	norm_A	B: num_cross_party_cosponsored_bills	norm_B	C: outcome_bipartisanship	norm_C	D: outcome_bipartisanship_pct	norm_D	attack_personal

0 rows × 23 columns

## Note: No missing values for House

# Fill missing with zero (no personal attacks)
house_final['attack_personal'] = house_final['attack_personal'].fillna(0)

# Normalize E - House
house_final['E: attack_personal'] = house_final['attack_personal']

# Recalculate mean and std
mean_E = house_final['attack_personal'].mean()
std_E = house_final['attack_personal'].std()

# Add normalized column
house_final['norm_E'] = 1- (norm.cdf(house_final['attack_personal'], mean_E, std_E) * 100)

# Cleanup
house_final.drop(columns=['attack_personal'], inplace=True)
if house_final['bioguide_id'].duplicated().any():
    house_final.drop_duplicates(subset='bioguide_id', inplace=True)

house_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	...	A: num_bills_with_cross_party_cosponsors	norm_A	B: num_cross_party_cosponsored_bills	norm_B	C: outcome_bipartisanship	norm_C	D: outcome_bipartisanship_pct	norm_D	E: attack_personal	norm_E
0	M001233	Mark B. Messmer	Mark	B.	Messmer	NaN	House	Indiana	8.0	Republican	...	1.0	20.874310	6	27.624352	2.0	15.141404	4.878049	43.384639	0.0	-26.829767
1	R000617	Delia C. Ramirez	Delia	C.	Ramirez	NaN	House	Illinois	3.0	Democratic	...	1.0	20.874310	19	41.338114	28.0	39.575556	1.842105	15.378290	117.0	-97.480720
2	M001229	LaMonica McIver	LaMonica	NaN	McIver	NaN	House	New Jersey	10.0	Democratic	...	1.0	20.874310	17	39.105279	8.0	19.666071	5.095541	45.801824	3.0	-29.246708
3	H001085	Chrissy Houlahan	Chrissy	NaN	Houlahan	NaN	House	Pennsylvania	6.0	Democratic	...	15.0	96.832815	73	90.981076	60.0	75.126253	7.633588	72.850883	64.0	-81.068324
4	M001226	Robert Menendez	Robert	NaN	Menendez	NaN	House	New Jersey	8.0	Democratic	...	2.0	26.754660	14	35.824398	36.0	48.857402	4.411765	38.295997	12.0	-36.997215

5 rows × 24 columns

Merge & Normalize for Senate#

# Merge into senate_final
senate_final = senate_final.merge(
    source_E,
    on='bioguide_id',
    how='left'
)

senate_final[senate_final[
    'attack_personal'].isna()]

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	...	image_url	A: num_bills_with_cross_party_cosponsors	norm_A	B: num_cross_party_cosponsored_bills	norm_B	C: outcome_bipartisanship	norm_C	D: outcome_bipartisanship_pct	norm_D	attack_personal

0 rows × 23 columns

## Note: No missing values for Senate

# Fill missing with zero
senate_final['attack_personal'] = senate_final['attack_personal'].fillna(0)

# Normalize E - Senate
senate_final['E: attack_personal'] = senate_final['attack_personal']

mean_E = senate_final['attack_personal'].mean()
std_E = senate_final['attack_personal'].std()

# Add normalized column
senate_final['norm_E'] = 1 - (norm.cdf(senate_final['attack_personal'], mean_E, std_E) * 100)

# Cleanup
if senate_final['bioguide_id'].duplicated().any():
    senate_final.drop_duplicates(subset='bioguide_id', inplace=True)
senate_final.drop(columns=['attack_personal'], inplace=True)

senate_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	...	A: num_bills_with_cross_party_cosponsors	norm_A	B: num_cross_party_cosponsored_bills	norm_B	C: outcome_bipartisanship	norm_C	D: outcome_bipartisanship_pct	norm_D	E: attack_personal	norm_E
0	S001232	Tim Sheehy	Tim	NaN	Sheehy	NaN	Senate	Montana	NaN	Republican	...	6	24.239891	24	29.006544	2.0	11.809128	4.000000	19.172695	0.0	-24.963767
1	L000570	Ben Ray Luján	Ben	Ray	Luján	NaN	Senate	New Mexico	NaN	Democratic	...	8	30.450752	57	75.553948	76.0	38.604383	6.959707	47.529597	53.0	-40.802397
2	H001089	Josh Hawley	Josh	NaN	Hawley	NaN	Senate	Missouri	NaN	Republican	...	13	48.258655	21	25.257922	9.0	13.568212	2.719033	11.086503	10.0	-27.708748
3	W000800	Peter Welch	Peter	NaN	Welch	NaN	Senate	Vermont	NaN	Democratic	...	15	55.703808	63	82.080297	198.0	88.214775	6.954689	47.474948	201.0	-83.489447
4	M001242	Bernie Moreno	Bernie	NaN	Moreno	NaN	Senate	Ohio	NaN	Republican	...	3	16.371664	13	16.645559	39.0	23.052655	6.280193	40.213106	5.0	-26.319176

5 rows × 24 columns

Source F: Attack_Personal (Pct)#

Penalizes Members of the 119th U.S. Congress based on the percentage of their communications that are personal attacks. Higher attack rates → lower scores. We fill true zero‐activity with zeros, then apply a normalization.

Data origin: American Political Pulse communications CSV (2025 download)
Download link: https://americaspoliticalpulse.com/data/ (Download “US officials – 2025”)
Date downloaded: August 8, 2025
Preprocessing notebook: Source C–D–E–F: App_Communications_Calculations

Why fill with zeros?
A missing attack_personal_pct means the legislator made no personal-attack communications. Zero correctly represents “none.”

Normalization
Using 1 – CDF ensures higher attack rates produce lower percentile scores.

Load & Validate Source F#

# Ensure expected column present
assert 'attack_personal_pct' in source_APP.columns, \
    "Missing 'attack_personal_pct' in source_APP"

# Subset and copy
source_F = source_APP[['bioguide_id','attack_personal_pct']].copy()
source_F.head()

	bioguide_id	attack_personal_pct
0	A000055	1.171875
1	A000148	8.416390
2	A000369	0.347222
3	A000370	1.052632
4	A000371	3.252033

# Merge into house_final
house_final = house_final.merge(
    source_F,
    on='bioguide_id',
    how='left'
)

house_final[house_final[
    'attack_personal_pct'].isna()]

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	...	norm_A	B: num_cross_party_cosponsored_bills	norm_B	C: outcome_bipartisanship	norm_C	D: outcome_bipartisanship_pct	norm_D	E: attack_personal	norm_E	attack_personal_pct

0 rows × 25 columns

## Note: No missing values for house

# Fill missing with zero (no personal attacks)
house_final['attack_personal_pct'] = \
    house_final['attack_personal_pct'].fillna(0)

# Normalize F - House
house_final['F: attack_personal_pct'] = house_final['attack_personal_pct']

# Recalculate mean and std
mean_F = house_final['attack_personal_pct'].mean()
std_F = house_final['attack_personal_pct'].std()

# Add normalized column
house_final['norm_F'] = 1 - (norm.cdf(house_final['attack_personal_pct'], mean_F, std_F) * 100)

# Cleanup
house_final.drop(columns=['attack_personal_pct'], inplace=True)
if house_final['bioguide_id'].duplicated().any():
    house_final.drop_duplicates(subset='bioguide_id', inplace=True)

house_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	...	B: num_cross_party_cosponsored_bills	norm_B	C: outcome_bipartisanship	norm_C	D: outcome_bipartisanship_pct	norm_D	E: attack_personal	norm_E	F: attack_personal_pct	norm_F
0	M001233	Mark B. Messmer	Mark	B.	Messmer	NaN	House	Indiana	8.0	Republican	...	6	27.624352	2.0	15.141404	4.878049	43.384639	0.0	-26.829767	0.000000	-18.702124
1	R000617	Delia C. Ramirez	Delia	C.	Ramirez	NaN	House	Illinois	3.0	Democratic	...	19	41.338114	28.0	39.575556	1.842105	15.378290	117.0	-97.480720	7.697368	-90.663706
2	M001229	LaMonica McIver	LaMonica	NaN	McIver	NaN	House	New Jersey	10.0	Democratic	...	17	39.105279	8.0	19.666071	5.095541	45.801824	3.0	-29.246708	1.910828	-37.305928
3	H001085	Chrissy Houlahan	Chrissy	NaN	Houlahan	NaN	House	Pennsylvania	6.0	Democratic	...	73	90.981076	60.0	75.126253	7.633588	72.850883	64.0	-81.068324	8.142494	-92.473988
4	M001226	Robert Menendez	Robert	NaN	Menendez	NaN	House	New Jersey	8.0	Democratic	...	14	35.824398	36.0	48.857402	4.411765	38.295997	12.0	-36.997215	1.470588	-32.531276

5 rows × 26 columns

Merge & Normalize for Senate#

# Merge into senate_final
senate_final = senate_final.merge(
    source_F,
    on='bioguide_id',
    how='left'
)

senate_final[senate_final[
    'attack_personal_pct'].isna()]

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	...	norm_A	B: num_cross_party_cosponsored_bills	norm_B	C: outcome_bipartisanship	norm_C	D: outcome_bipartisanship_pct	norm_D	E: attack_personal	norm_E	attack_personal_pct

0 rows × 25 columns

## Note: No missing values for Senate

# Fill missing with zero
senate_final['attack_personal_pct'] = \
    senate_final['attack_personal_pct'].fillna(0)

# Normalize F - Senate
senate_final['F: attack_personal_pct'] = senate_final['attack_personal_pct']

# Recalculate mean and std
mean_F = senate_final['attack_personal_pct'].mean()
std_F = senate_final['attack_personal_pct'].std()

# Add normalized column
senate_final['norm_F'] = 1 - (norm.cdf(senate_final['attack_personal_pct'], mean_F, std_F) * 100)

# Cleanup
if senate_final['bioguide_id'].duplicated().any():
    senate_final.drop_duplicates(subset='bioguide_id', inplace=True)
senate_final.drop(columns=['attack_personal_pct'], inplace=True)

senate_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	...	B: num_cross_party_cosponsored_bills	norm_B	C: outcome_bipartisanship	norm_C	D: outcome_bipartisanship_pct	norm_D	E: attack_personal	norm_E	F: attack_personal_pct	norm_F
0	S001232	Tim Sheehy	Tim	NaN	Sheehy	NaN	Senate	Montana	NaN	Republican	...	24	29.006544	2.0	11.809128	4.000000	19.172695	0.0	-24.963767	0.000000	-16.609602
1	L000570	Ben Ray Luján	Ben	Ray	Luján	NaN	Senate	New Mexico	NaN	Democratic	...	57	75.553948	76.0	38.604383	6.959707	47.529597	53.0	-40.802397	4.853480	-54.253098
2	H001089	Josh Hawley	Josh	NaN	Hawley	NaN	Senate	Missouri	NaN	Republican	...	21	25.257922	9.0	13.568212	2.719033	11.086503	10.0	-27.708748	3.021148	-38.395311
3	W000800	Peter Welch	Peter	NaN	Welch	NaN	Senate	Vermont	NaN	Democratic	...	63	82.080297	198.0	88.214775	6.954689	47.474948	201.0	-83.489447	7.060063	-72.074555
4	M001242	Bernie Moreno	Bernie	NaN	Moreno	NaN	Senate	Ohio	NaN	Republican	...	13	16.645559	39.0	23.052655	6.280193	40.213106	5.0	-26.319176	0.805153	-21.539411

5 rows × 26 columns

Source M: Cook Political Partisan Voting Index (PVI)#

This section processes Source M, which captures each district’s partisan lean (Cook PVI) for the 119th Congress. A higher PVI number means a stronger lean toward one party; a lower PVI indicates a more competitive (centrist) district. We cap the PVI value at 15. If the representative’s party does not match the party of the PVI lean, PVI number is set at 0.

Data origin: Cook Political PVI via subscription at cookpolitical.com
Date downloaded: April, 2025 (this data is updated periodically, not daily)
Preprocessing notebook: Source M House & Senate Cook Political PVI

Merge & Cap for House#

# Identify the PVI column
pvi_cols = [c for c in source_M_House.columns if "PVI_Number" in c]
assert pvi_cols, f"No PVI number column found in source_M_House: {source_M_House.columns.tolist()}"
pvi_col = pvi_cols[0]

# Subset and rename
source_M_h = source_M_House[['bioguide_id', pvi_col]].copy()
source_M_h.rename(columns={pvi_col: 'Cook PVI Raw'}, inplace=True)
source_M_h.head()

	bioguide_id	Cook PVI Raw
0	M001233	18
1	R000617	17
2	M001229	27
3	H001085	6
4	M001226	15

# Caping Value of PVI to pvi_value_cap in bonuses dictionary
pvi_value_cap = bonuses['pvi_value_cap']

source_M_h[source_M_h['Cook PVI Raw'] > pvi_value_cap]

	bioguide_id	Cook PVI Raw
0	M001233	18
1	R000617	17
2	M001229	27
5	F000477	23
6	T000488	22
...	...	...
424	P000197	36
425	T000460	17
426	A000055	33
429	M001212	27
430	R000575	23

153 rows × 2 columns

source_M_h['Cook PVI Raw'] = source_M_h['Cook PVI Raw'].apply(lambda x: pvi_value_cap if x > pvi_value_cap else x)

# Check
source_M_h[source_M_h['Cook PVI Raw'] > pvi_value_cap]

	bioguide_id	Cook PVI Raw

# Merge into house_final
house_final = house_final.merge(
    source_M_h,
    on='bioguide_id',
    how='left'
)

house_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	...	norm_B	C: outcome_bipartisanship	norm_C	D: outcome_bipartisanship_pct	norm_D	E: attack_personal	norm_E	F: attack_personal_pct	norm_F	Cook PVI Raw
0	M001233	Mark B. Messmer	Mark	B.	Messmer	NaN	House	Indiana	8.0	Republican	...	27.624352	2.0	15.141404	4.878049	43.384639	0.0	-26.829767	0.000000	-18.702124	15
1	R000617	Delia C. Ramirez	Delia	C.	Ramirez	NaN	House	Illinois	3.0	Democratic	...	41.338114	28.0	39.575556	1.842105	15.378290	117.0	-97.480720	7.697368	-90.663706	15
2	M001229	LaMonica McIver	LaMonica	NaN	McIver	NaN	House	New Jersey	10.0	Democratic	...	39.105279	8.0	19.666071	5.095541	45.801824	3.0	-29.246708	1.910828	-37.305928	15
3	H001085	Chrissy Houlahan	Chrissy	NaN	Houlahan	NaN	House	Pennsylvania	6.0	Democratic	...	90.981076	60.0	75.126253	7.633588	72.850883	64.0	-81.068324	8.142494	-92.473988	6
4	M001226	Robert Menendez	Robert	NaN	Menendez	NaN	House	New Jersey	8.0	Democratic	...	35.824398	36.0	48.857402	4.411765	38.295997	12.0	-36.997215	1.470588	-32.531276	15

5 rows × 27 columns

Merge & Cap for Senate#

# Identify PVI column in source_M_Senate
pvi_cols_s = [c for c in source_M_Senate.columns if "PVI_Number" in c]
assert pvi_cols_s, f"No PVI number column found in source_M_Senate: {source_M_Senate.columns.tolist()}"
pvi_col_s = pvi_cols_s[0]

# Subset and rename
source_M_s = source_M_Senate[['bioguide_id', pvi_col_s]].copy()
source_M_s.rename(columns={pvi_col_s: 'Cook PVI Raw'}, inplace=True)
source_M_s.head()

	bioguide_id	Cook PVI Raw
0	S001232	10
1	L000570	4
2	H001089	9
3	W000800	17
4	M001242	5

# Caping Value of PVI to pvi_value_cap in bonuses dictionary
pvi_value_cap = bonuses['pvi_value_cap']

source_M_s[source_M_s['Cook PVI Raw'] > pvi_value_cap]

	bioguide_id	Cook PVI Raw
3	W000800	17
40	R000584	18
46	M001190	17
51	L000571	23
58	L000575	17
62	J000312	21
65	H001061	18
82	C000880	18
84	C001096	18
90	C001047	21
96	B001261	23

source_M_s['Cook PVI Raw'] = source_M_s['Cook PVI Raw'].apply(lambda x: pvi_value_cap if x > pvi_value_cap else x)

# Check
source_M_s[source_M_s['Cook PVI Raw'] > pvi_value_cap]

	bioguide_id	Cook PVI Raw

# Merge into senate_final
senate_final = senate_final.merge(
    source_M_s,
    on='bioguide_id',
    how='left'
)
senate_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	...	norm_B	C: outcome_bipartisanship	norm_C	D: outcome_bipartisanship_pct	norm_D	E: attack_personal	norm_E	F: attack_personal_pct	norm_F	Cook PVI Raw
0	S001232	Tim Sheehy	Tim	NaN	Sheehy	NaN	Senate	Montana	NaN	Republican	...	29.006544	2.0	11.809128	4.000000	19.172695	0.0	-24.963767	0.000000	-16.609602	10
1	L000570	Ben Ray Luján	Ben	Ray	Luján	NaN	Senate	New Mexico	NaN	Democratic	...	75.553948	76.0	38.604383	6.959707	47.529597	53.0	-40.802397	4.853480	-54.253098	4
2	H001089	Josh Hawley	Josh	NaN	Hawley	NaN	Senate	Missouri	NaN	Republican	...	25.257922	9.0	13.568212	2.719033	11.086503	10.0	-27.708748	3.021148	-38.395311	9
3	W000800	Peter Welch	Peter	NaN	Welch	NaN	Senate	Vermont	NaN	Democratic	...	82.080297	198.0	88.214775	6.954689	47.474948	201.0	-83.489447	7.060063	-72.074555	15
4	M001242	Bernie Moreno	Bernie	NaN	Moreno	NaN	Senate	Ohio	NaN	Republican	...	16.645559	39.0	23.052655	6.280193	40.213106	5.0	-26.319176	0.805153	-21.539411	5

5 rows × 27 columns

Source N: Voteview Member Ideology Score#

This section merges pre-computed ideology percentiles into the Bridge Pledge tables. The percentiles measure how far each legislator lies from the partisan center, rewarding those closer to the middle.

Data source: Voteview “Member Ideology” CSV exports (House and Senate, 119th Congress)
Date downloaded: August 8, 2025
Preprocessing notebook: Source N: VoteView Member Ideology Scores.ipynb
Preprocessed outputs:
- bridge_grade_source_n_house_ideology.csv
- bridge_grade_source_n_senate_ideology.csv
Columns:
- bioguide_id
- Nominate_dim1 (NOMINATE D1 value)
- ideology_dist (absolute NOMINATE D1 distance)

We simply merge the final ideology_dist as N: ideology_score into our pledge tables for both chambers.

# Confirm available columns in the preprocessed N files
print(source_N_House.columns)
print(source_N_Senate.columns)

Index(['Name', 'bioguide_id', 'nominate_dim1', 'ideology_dist'], dtype='object')
Index(['Name', 'bioguide_id', 'nominate_dim1', 'ideology_dist'], dtype='object')

# Merge into house final
# Merge only the percentile column
house_final = house_final.merge(
    source_N_House[['bioguide_id', 'nominate_dim1', 'ideology_dist']],
    on='bioguide_id',
    how='left'
)

# Merge into senate final
senate_final = senate_final.merge(
    source_N_Senate[['bioguide_id', 'nominate_dim1', 'ideology_dist']],
    on='bioguide_id',
    how='left'
)

house_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	...	norm_C	D: outcome_bipartisanship_pct	norm_D	E: attack_personal	norm_E	F: attack_personal_pct	norm_F	Cook PVI Raw	nominate_dim1	ideology_dist
0	M001233	Mark B. Messmer	Mark	B.	Messmer	NaN	House	Indiana	8.0	Republican	...	15.141404	4.878049	43.384639	0.0	-26.829767	0.000000	-18.702124	15	0.468	0.468
1	R000617	Delia C. Ramirez	Delia	C.	Ramirez	NaN	House	Illinois	3.0	Democratic	...	39.575556	1.842105	15.378290	117.0	-97.480720	7.697368	-90.663706	15	-0.496	0.496
2	M001229	LaMonica McIver	LaMonica	NaN	McIver	NaN	House	New Jersey	10.0	Democratic	...	19.666071	5.095541	45.801824	3.0	-29.246708	1.910828	-37.305928	15	-0.603	0.603
3	H001085	Chrissy Houlahan	Chrissy	NaN	Houlahan	NaN	House	Pennsylvania	6.0	Democratic	...	75.126253	7.633588	72.850883	64.0	-81.068324	8.142494	-92.473988	6	-0.259	0.259
4	M001226	Robert Menendez	Robert	NaN	Menendez	NaN	House	New Jersey	8.0	Democratic	...	48.857402	4.411765	38.295997	12.0	-36.997215	1.470588	-32.531276	15	-0.520	0.520

5 rows × 29 columns

senate_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	...	norm_C	D: outcome_bipartisanship_pct	norm_D	E: attack_personal	norm_E	F: attack_personal_pct	norm_F	Cook PVI Raw	nominate_dim1	ideology_dist
0	S001232	Tim Sheehy	Tim	NaN	Sheehy	NaN	Senate	Montana	NaN	Republican	...	11.809128	4.000000	19.172695	0.0	-24.963767	0.000000	-16.609602	10	0.666	0.666
1	L000570	Ben Ray Luján	Ben	Ray	Luján	NaN	Senate	New Mexico	NaN	Democratic	...	38.604383	6.959707	47.529597	53.0	-40.802397	4.853480	-54.253098	4	-0.378	0.378
2	H001089	Josh Hawley	Josh	NaN	Hawley	NaN	Senate	Missouri	NaN	Republican	...	13.568212	2.719033	11.086503	10.0	-27.708748	3.021148	-38.395311	9	0.832	0.832
3	W000800	Peter Welch	Peter	NaN	Welch	NaN	Senate	Vermont	NaN	Democratic	...	88.214775	6.954689	47.474948	201.0	-83.489447	7.060063	-72.074555	15	-0.407	0.407
4	M001242	Bernie Moreno	Bernie	NaN	Moreno	NaN	Senate	Ohio	NaN	Republican	...	23.052655	6.280193	40.213106	5.0	-26.319176	0.805153	-21.539411	5	0.767	0.767

5 rows × 29 columns

Section: Prepare & Apply “Problem Solvers Caucus” Bump#

Below we first export the hard-coded caucus list to a CSV so it can be maintained externally, then load it and apply the bump to both House and Senate tables.

### 1. Export Problem Solvers Caucus IDs to CSV

# Create the hard-coded list of PSC members
problem_solvers = {
    'Name': [
        'Brian Fitzpatrick', 'Tom Suozzi', 'Josh Gottheimer', 'Ed Case',
        'Nicole Malliotakis', 'Andrew Garbarino', 'Don Bacon', 'Salud Carbajal',
        'Rob Bresnahan', 'Juan Ciscomani', 'Ben Cline', 'Jim Costa',
        'Angie Craig', 'Henry Cuellar', 'Don Davis', 'Debbie Dingell',
        'Chuck Edwards', 'Gabe Evans', 'Marie Gluesenkamp Perez', 'Jared Golden',
        'Josh Harder', 'Chrissy Houlahan', 'Steven Horsford', 'Greg Landsman',
        'Susie Lee', 'Donald Norcross', 'Jimmy Panetta', 'Chris Pappas',
        'Scott Peters', 'Brittany Pettersen', 'Brad Schneider', 'Hillary Scholten',
        'Darren Soto', 'Haley Stevens', 'Emilia Sykes', 'Dusty Johnson',
        'David Joyce', 'Thomas Kean Jr.', 'Young Kim', 'Nick LaLota',
        'Mike Lawler', 'Daniel Meuser', 'Blake Moore', 'James Moylan',
        'Maria Elvira Salazar', 'Bryan Steil', 'David Valadao','Jennifer A. Kiggans',
        'Jeff Hurd'
    ],
    'bioguide_id': [
        'F000466', 'S001201', 'G000583', 'C001055',
        'M000317', 'G000597', 'B001298', 'C001112',
        'B001327', 'C001133', 'C001118', 'C001059',
        'C001119', 'C001063', 'D000230', 'D000624',
        'E000246', 'E000300', 'G000600', 'G000592',
        'H001090', 'H001085', 'H001066', 'L000601',
        'L000590', 'N000188', 'P000613', 'P000614',
        'P000608', 'P000620', 'S001190', 'S001221',
        'S001200', 'S001215', 'S001223', 'J000301',
        'J000295', 'K000398', 'K000397', 'L000598',
        'L000599', 'M001204', 'M001213', 'M001219',
        'S000168', 'S001213', 'V000129', 'K000399',
        'H001100'
    ]
}

# Convert to DataFrame and export
ps_df = pd.DataFrame(problem_solvers)
ps_df[['bioguide_id']].to_csv(
    '/content/drive/MyDrive/Bridge Grades Snapshot August/Data/Source P/problem_solvers.csv',
    index=False
)

Source P: Problem Solvers Caucus “Bump”#

This section applies a fixed points boost to members of the Problem Solvers Caucus (PSC). We load the externally maintained list of PSC bioguide IDs, flag each legislator, and add the configured bonus (ps_score) to their pledge score.

Data source: problem_solvers.csv (one column: bioguide_id), maintained in our data repo. Source: https://problemsolverscaucus.house.gov/caucus-members
Date Updated: August 8, 2025
Outputs added:
- P_flag (0 or 1)

# Load the external CSV of caucus members
psc_ids = set(
    pd.read_csv(
        '/content/drive/MyDrive/Bridge Grades Snapshot August/Data/Source P/problem_solvers.csv'
    )['bioguide_id']
)

def apply_psc_bump(df, id_col='bioguide_id'):
    """
    Add PSC bump:
      - P_flag: 1 if member is in PSC, else 0
    """
    df = df.copy()
    df['P_flag'] = df[id_col].isin(psc_ids).astype(int)
    return df

# Check for any PSC IDs not present in the House roster
missing_in_house = psc_ids - set(house_final['bioguide_id'])
if missing_in_house:
    print(f"Warning: PSC IDs not in House table: {sorted(missing_in_house)}")

# Apply PSC bump to House
house_final = apply_psc_bump(house_final)
house_final.head()

Warning: PSC IDs not in House table: ['M001219']

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	...	D: outcome_bipartisanship_pct	norm_D	E: attack_personal	norm_E	F: attack_personal_pct	norm_F	Cook PVI Raw	nominate_dim1	ideology_dist	P_flag
0	M001233	Mark B. Messmer	Mark	B.	Messmer	NaN	House	Indiana	8.0	Republican	...	4.878049	43.384639	0.0	-26.829767	0.000000	-18.702124	15	0.468	0.468	0
1	R000617	Delia C. Ramirez	Delia	C.	Ramirez	NaN	House	Illinois	3.0	Democratic	...	1.842105	15.378290	117.0	-97.480720	7.697368	-90.663706	15	-0.496	0.496	0
2	M001229	LaMonica McIver	LaMonica	NaN	McIver	NaN	House	New Jersey	10.0	Democratic	...	5.095541	45.801824	3.0	-29.246708	1.910828	-37.305928	15	-0.603	0.603	0
3	H001085	Chrissy Houlahan	Chrissy	NaN	Houlahan	NaN	House	Pennsylvania	6.0	Democratic	...	7.633588	72.850883	64.0	-81.068324	8.142494	-92.473988	6	-0.259	0.259	1
4	M001226	Robert Menendez	Robert	NaN	Menendez	NaN	House	New Jersey	8.0	Democratic	...	4.411765	38.295997	12.0	-36.997215	1.470588	-32.531276	15	-0.520	0.520	0

5 rows × 30 columns

### Note: Bioguide 'M001219' is James C. Moylan. They are a non-voting member of Guam.
### Note: Only House members are included in the PSC, so this is not applicable to the Senate.
senate_final["P_flag"] = 0

# Final check of the number of members in the house and senate
print(house_final.shape[0])
print(senate_final.shape[0])

431
100

Score Calculation & Final Grades#

In this final phase, we turn each legislator’s normalized source scores into a composite Bridge Grade. We:

Combine weighted normalized scores from each Source (A–F).
Apply multipliers (M, N, P) on top of the normalized, weighted score.
Assign a letter grade (A, B, C, F) based on statistical thresholds (mean ± std and the median).
Normalize the combined score to a 0–100 percentile.

Below are three subsections: building the scoring function, generating & exporting final tables, and visualizing the grade distributions.

Build the Scoring Function#

We create cal_score(), which:

Aggregates norm_{X} columns only if they exist in the DataFrame.
Weights Assigns the weights.
Addsideology multipliers (M, N, P) safely, with the following formulas:
- bonus_m = [(score_T*(1+M)*max_P_bonus_scaling_factor)-score_T]
- bonus_n = score_T* max_N_bonus_scaling_factor *ideology_dist
- bonus_p = max_P_bonus_scaling_factor* score_T_max *P_flag where score_T_max is the max score_T across all legislators
score_U = score_T + bonus_m + bonus_n + bonus_p
Normalizes the total (score_T) via the Normal CDF.
Assigns letter grades using:
- A if score_U > mean + std
- B if median < score_U ≤ mean + std
- C if mean - std < score_U ≤ median
- F otherwise

house_final.head()

	bioguide_id	Name	first_name	middle_name	last_name	nickname	Chamber	State	District	Party	...	D: outcome_bipartisanship_pct	norm_D	E: attack_personal	norm_E	F: attack_personal_pct	norm_F	Cook PVI Raw	nominate_dim1	ideology_dist	P_flag
0	M001233	Mark B. Messmer	Mark	B.	Messmer	NaN	House	Indiana	8.0	Republican	...	4.878049	43.384639	0.0	-26.829767	0.000000	-18.702124	15	0.468	0.468	0
1	R000617	Delia C. Ramirez	Delia	C.	Ramirez	NaN	House	Illinois	3.0	Democratic	...	1.842105	15.378290	117.0	-97.480720	7.697368	-90.663706	15	-0.496	0.496	0
2	M001229	LaMonica McIver	LaMonica	NaN	McIver	NaN	House	New Jersey	10.0	Democratic	...	5.095541	45.801824	3.0	-29.246708	1.910828	-37.305928	15	-0.603	0.603	0
3	H001085	Chrissy Houlahan	Chrissy	NaN	Houlahan	NaN	House	Pennsylvania	6.0	Democratic	...	7.633588	72.850883	64.0	-81.068324	8.142494	-92.473988	6	-0.259	0.259	1
4	M001226	Robert Menendez	Robert	NaN	Menendez	NaN	House	New Jersey	8.0	Democratic	...	4.411765	38.295997	12.0	-36.997215	1.470588	-32.531276	15	-0.520	0.520	0

5 rows × 30 columns

def cal_score(data, weights, bonuses):
    # Copy the data to avoid modifying the original dataframe
    temp_data = data.copy()

    # Initialize columns
    temp_data['score_T'] = 0

    # Calculate 'score_T' by adding weighted norm values for each category
    for i in weights.keys():
        temp_data['score_T'] += temp_data[f"norm_{i}"] * weights[i]


    # Calculate scores for ideology multipliers BEFORE the caucus score
    # Add bonuses
    temp_data['bonus_m'] = (temp_data['score_T']*(1+(temp_data['Cook PVI Raw']/100)*bonuses['max_M_bonus_scaling_factor']))-temp_data['score_T']


    temp_data['bonus_n'] = temp_data['score_T'] * bonuses['max_N_bonus_scaling_factor'] * temp_data['ideology_dist']

    #the bonuses M and N to 0 if they are negative

    temp_data['bonus_m'] = temp_data['bonus_m'].clip(lower=0)
    temp_data['bonus_n'] = temp_data['bonus_n'].clip(lower=0)


    temp_data['bonus_p'] = np.ceil(
      bonuses['max_P_bonus_scaling_factor']
      * temp_data['score_T'].max()
      * temp_data['P_flag']
    ).astype(int)

    print( temp_data['bonus_p'] )
    print(temp_data['score_T'].max())

    temp_data['score_U'] = temp_data['score_T'] + temp_data['bonus_m'] + temp_data['bonus_n'] + temp_data['bonus_p']

    # Calculate mean, std, and median of 'score_S'
    mean_U = round(temp_data['score_U'].mean(), 2)
    std_U = round(temp_data['score_U'].std(), 2)
    median_U = round(temp_data['score_U'].median(), 2)

    # Normalize 'score_U' using the cumulative distribution function (CDF)
    temp_data['norm_U'] = norm.cdf(temp_data['score_U'], mean_U, std_U) * 100

    # Define the grade assignment function based on the calculated scores
    def assign_grade(grade):
        if grade > mean_U + std_U:
            return 'A'
        elif grade > median_U:
            return 'B'
        elif grade > mean_U - std_U:
            return 'C'
        else:
            return 'F'

    # Apply the grade assignment to the 'score_S' column
    temp_data['Grade'] = temp_data['score_U'].apply(assign_grade)

    return temp_data

house_final_test = cal_score(house_final,  weights, bonuses)

    0
    0
    0
    7
    0
      ..
  0
  0
  0
  0
  0
Name: bonus_p, Length: 431, dtype: int64
6490811028898

house_final_test['Grade'].value_counts()

	count
Grade
C	153
B	139
A	77
F	62

dtype: int64

senate_final_test = cal_score(senate_final,  weights, bonuses)

   0
   0
   0
   0
   0
     ..
  0
  0
  0
  0
  0
Name: bonus_p, Length: 100, dtype: int64
5370609849944

senate_final_test["Grade"].value_counts()

	count
Grade
B	36
C	27
F	23
A	14

dtype: int64

import seaborn as sns
import matplotlib.pyplot as plt

order = ["A", "B", "C", "F"]
hue_order = ['Democratic', 'Republican', 'Independent']

purple_palette = ["#4B0082", "#5D3FD3", "#7B68EE"]

def plot_with_counts(data, title):
    ax = sns.countplot(
        x='Grade',
        hue='Party',
        data=data,
        palette=purple_palette,
        order=order,
        hue_order=hue_order
    )
    ax.set_title(title)

    # Calcular el valor máximo para ajustar el límite superior
    max_height = max([p.get_height() for p in ax.patches])
    ax.set_ylim(0, max_height * 1.15)  # 15% extra arriba

    # Etiquetas
    for p in ax.patches:
        height = int(p.get_height())
        if height > 0:
            ax.annotate(
                f'{height}',
                (p.get_x() + p.get_width() / 2., height),
                ha='center', va='bottom',
                fontsize=9, color='black', xytext=(0, 3),
                textcoords='offset points'
            )

    plt.show()

# House
plot_with_counts(house_final_test, "House Bridge Grade Distribution")

# Senate
plot_with_counts(senate_final_test, "Senate Bridge Grade Distribution")

_images/dbfe7f24a307245041d60d1cd1f971dc7bf279928c606d9d6e981cfcf0d08659.png

_images/2bb97e1318571e691403afd65f7cc3d347dd0ae4d65f09968e9a09eefa7b7e1d.png

Clean up for final output#

Party#

# meta_data["Party"] is R, if the party is Republican, D if Democrat, I if Independent
house_final_test["Party_Abbr"] = house_final_test["Party"].replace({
    "Republican": "R",
    "Democratic": "D",
    "Independent": "I"
})

# meta_data["Party"] is R, if the party is Republican, D if Democrat, I if Independent
senate_final_test["Party_Abbr"] = senate_final_test["Party"].replace({
    "Republican": "R",
    "Democratic": "D",
    "Independent": "I"
})

district and state_district#

# State name → USPS abbreviations

state_abbr = {
    'Alabama': 'AL', 'Alaska': 'AK', 'Arizona': 'AZ', 'Arkansas': 'AR', 'California': 'CA',
    'Colorado': 'CO', 'Connecticut': 'CT', 'Delaware': 'DE', 'Florida': 'FL', 'Georgia': 'GA',
    'Hawaii': 'HI', 'Idaho': 'ID', 'Illinois': 'IL', 'Indiana': 'IN', 'Iowa': 'IA',
    'Kansas': 'KS', 'Kentucky': 'KY', 'Louisiana': 'LA', 'Maine': 'ME', 'Maryland': 'MD',
    'Massachusetts': 'MA', 'Michigan': 'MI', 'Minnesota': 'MN', 'Mississippi': 'MS', 'Missouri': 'MO',
    'Montana': 'MT', 'Nebraska': 'NE', 'Nevada': 'NV', 'New Hampshire': 'NH', 'New Jersey': 'NJ',
    'New Mexico': 'NM', 'New York': 'NY', 'North Carolina': 'NC', 'North Dakota': 'ND', 'Ohio': 'OH',
    'Oklahoma': 'OK', 'Oregon': 'OR', 'Pennsylvania': 'PA', 'Rhode Island': 'RI', 'South Carolina': 'SC',
    'South Dakota': 'SD', 'Tennessee': 'TN', 'Texas': 'TX', 'Utah': 'UT', 'Vermont': 'VT',
    'Virginia': 'VA', 'Washington': 'WA', 'West Virginia': 'WV', 'Wisconsin': 'WI', 'Wyoming': 'WY', 'District of Columbia':'DC'

}

house_final_test['State_Abbr'] = house_final_test['State'].str.strip().map(state_abbr)
senate_final_test['State_Abbr'] = senate_final_test['State'].str.strip().map(state_abbr)

# Build "State_District" key with zero-padded two digits
def make_sd(df, state_col, dist_col):

    # Convert district strings to numeric, default 1 for non‐numeric (at‐large)
    dist_num = pd.to_numeric(df[dist_col], errors='coerce').fillna(1).replace(0, 1).astype(int)

    # Zero‐pad to two digits
    dist_str = dist_num.apply(lambda d: f"{d:02d}")
    return df[state_col].astype(str) + '-' + dist_str

house_final_test['District_Abbr'] = make_sd(house_final_test,  'State_Abbr', 'District')
senate_final_test['District_Abbr'] = senate_final_test['State_Abbr']

# List of at-large state abbreviations
at_large_states = ['AK', 'DE', 'ND', 'SD', 'VT', 'WY']

# Update District_Abbr only for at-large states
house_final_test.loc[house_final_test['State_Abbr'].isin(at_large_states), 'District_Abbr'] = \
    house_final_test['State_Abbr'] + '-AL'

Reorganize columns#

house_final_test=house_final_test[['bioguide_id', 'Name', 'first_name', 'middle_name', 'last_name',
       'nickname', 'Chamber', 'State','State_Abbr', 'District','District_Abbr', 'Party', 'Party_Abbr', 'start_year',
       'end_year', 'update_date', 'image_url',
       'A: num_bills_with_cross_party_cosponsors', 'norm_A',
       'B: num_cross_party_cosponsored_bills', 'norm_B',
       'C: outcome_bipartisanship', 'norm_C', 'D: outcome_bipartisanship_pct',
       'norm_D', 'E: attack_personal', 'norm_E', 'F: attack_personal_pct',
       'norm_F', 'Cook PVI Raw', 'nominate_dim1', 'ideology_dist', 'P_flag',
       'score_T', 'bonus_m', 'bonus_n', 'bonus_p', 'score_U', 'norm_U',
       'Grade']]

senate_final_test=senate_final_test[['bioguide_id', 'Name', 'first_name', 'middle_name', 'last_name',
       'nickname', 'Chamber', 'State','State_Abbr', 'District','District_Abbr', 'Party', 'Party_Abbr', 'start_year',
       'end_year', 'update_date', 'image_url',
       'A: num_bills_with_cross_party_cosponsors', 'norm_A',
       'B: num_cross_party_cosponsored_bills', 'norm_B',
       'C: outcome_bipartisanship', 'norm_C', 'D: outcome_bipartisanship_pct',
       'norm_D', 'E: attack_personal', 'norm_E', 'F: attack_personal_pct',
       'norm_F', 'Cook PVI Raw', 'nominate_dim1', 'ideology_dist', 'P_flag',
       'score_T', 'bonus_m', 'bonus_n', 'bonus_p', 'score_U', 'norm_U',
       'Grade']]

# Export to Excel
house_final_test.to_excel(f'house_scores_119_{datetime.now().strftime("%Y-%m-%d")}.xlsx',  sheet_name='119 Grades', index=False)
senate_final_test.to_excel(f'senate_scores_119_{datetime.now().strftime("%Y-%m-%d")}.xlsx', sheet_name='119 Grades', index=False)

Bridge Grades Calculation: Final Bridge Grade Calculation Engine

Contents

Bridge Grades Calculation: Final Bridge Grade Calculation Engine#

Data Sources#

Input Files#

Output Files#

Main Functions#

1. Configuration and Setup#

2. Attendance Filtering#

3. Data Source Integration#

4. Final Score Calculation#

Outputs#

Final Datasets#

Key Columns in Output#

Technical Requirements#

Dependencies#

Data Processing Notes#

Data Quality#

Validation Checks#

Notebook Walkthrough: Bridge Grades Calculation#

Configuration & File Existence Checks#

Load DataFrames & Validate Weights#

Build Base Member Tables#

Attendance Filtering#

Source A: Authors of Bills with Cross-Party Sponsors#

Load & Prepare Source A#

Merge & Normalize for House#

Merge & Normalize for Senate#

Source B: Ranked People Who Cosponsor Bills#

Load & Prepare Source B#

Merge & Normalize for House#

Merge & Normalize for Senate#

Source C: Communication – Bipartisanship (Sum)#

Load & Prepare Source C#

Merge & Normalize for Senate#

Source D: Communication – Bipartisanship (Mean)#

Load & Prepare Source D#

Merge & Normalize for Senate#

Source E: Attack_Personal (Sum)#

Load & Prepare Source E#

Merge & Normalize for House#

Merge & Normalize for Senate#

Source F: Attack_Personal (Pct)#

Load & Validate Source F#

Merge & Normalize for Senate#

Source M: Cook Political Partisan Voting Index (PVI)#

Merge & Cap for House#

Merge & Cap for Senate#

Source N: Voteview Member Ideology Score#

Section: Prepare & Apply “Problem Solvers Caucus” Bump#

Source P: Problem Solvers Caucus “Bump”#

Score Calculation & Final Grades#

Build the Scoring Function#

Clean up for final output#

Party#

district and state_district#

Reorganize columns#
